Name: Super CO2
Brand Name: FEIYU
Delivery Method: Home Delivery
OEM/ODM: Free Design
Suitable for: Beauty Salons, Hospitals, Skin Care Centers, Spas, etc.
Machine Language: English (Customized System Language Supported)
Origin: Malacca, Malaysia
Payment Method: Cash, Debit Card and Credit Card
Shipping: 7-30 Days Shipping
Warranty: Lifetime Return and Refund for Quality Issues
Certificate: MDA, FDA
Category: CO2 Laser
Description
Basic Specifications
Parameter Name
Parameter Value
Instrument Dimensions
73 × 50 × 93 cm
Packaging Dimensions
90 × 57 × 119 cm
Instrument Weight
69 kg
Electrical Specifications
Parameter Name
Parameter Value
Description
Power Supply
Single-phase 220V
Must match the voltage indicated on the machine.
Max Output Current
No more than 10A
It is recommended to use a 3000W voltage stabilizer to reduce grid fluctuations.
Fractional Mode Parameters
Parameter Name
Setting Range
Description
Power (Laser)
0.5 W – 40 W
Energy per dot (PE).
Dwell Time (Duration)
0.1 ms – 10 ms
Duration of laser at each spot.
Pulse Interval (Repeat Interval)
1 ms – 5000 ms
Time interval between two consecutive spots.
Spot Spacing (Distance)
0.1 mm – 2.6 mm
Distance between spots, affecting coverage rate (PE).
Shape (Pattern)
Line, Square, Rectangle, Triangle, Hexagon, Circle, Ellipse
Laser pattern options.
Pattern Size
2 mm – 20 mm (Scanning mode)
Adjustable via up/down or zoom buttons.
Scanning Mode
Random Play, One-side Sequence, Max Distance Between Two Points
Three scanning modes available; changes with each press.
Normal Mode Parameters
Parameter Name
Setting Range
Description
Emission Energy (Power)
1% – 100%
Adjustable laser output energy.
Transmission Mode
Continuous, Single, Pulse
Different laser emission modes.
Burn Time (ON Time)
Single Pulse: 10 ms – 100 ms
Pulse Mode: 15 ms – (value not specified)
Duration of laser emission.
Interval Time (OFF Time)
Pulse Mode: 10 ms – 1000 ms
Time interval between pulses.
Gynecological Mode Parameters
Parameter Name
Setting Range
Description
Laser Scanning Mode
Sequential Scan, Random Scan
Scanning method within 360°, maximum distance can be set.
Number of Laser Treatments
Up to 10 times, commonly 1 time
Repeated treatments on the same area.
Sculpting Size (Shape Size)
Adjusted via +/- keys (range not specified)
Size of the cone scanned by laser.
Spot Duration (Dwell Time)
1 – 10, commonly 2 – 5
Spot dwell time, determines energy level.
Laser Power
1 – 40, commonly 33 – 40
Laser output power, determines energy intensity.
Number of Dots per Circle
Adjusted in multiples of 4, max 100, commonly 1 – 28
Number of laser dots in a 360° circle; too high may damage vaginal tissue.
Number of Scanning Lines
Up to 10 circles, commonly 1 – 2 circles
Number of laser scanning rounds.
External Genitalia Mode Parameters
Parameter Name
Setting Range
Description
Laser Scanning Mode
Sequential, Random, Max Distance (adjustable via +/- keys)
Scanning method within 360°.
Number of Laser Treatments
Up to 10 times, commonly 1 time
Repeated treatments on the same area.
Spot Duration (Dwell Time)
1 – 10, commonly 2 – 5
Spot dwell time, determines energy level.
Laser Power
1 – 40, commonly 33 – 40
Laser output power, determines energy intensity.
Shape Selection
Rectangle, Circle
Laser emission shape options.
Pattern Size
4.0 mm – 20 mm
Adjustable via up/down or zoom buttons.
Product Details
